CNC MILLING DIVISION



At the Front Of Our Shop Are Our Vertical CNC Mills and Our Large Size Horizontal CNC Mill.

From Compact And Robust To Large & Powerful, We Have The Right Machine For The Job.

TOSHIBA  BMC-800E

X - 1600 mm

Y - 1000 mm

Z - 1200 mm


OKK  VM53R

X - 1050 mm

Y - 650 mm

Z - 660 mm


SMART MACHINE TOOL

SM1365

X - 1360 mm

Y - 650 mm

Z - 600 mm


SMART MACHINE TOOL

SM1365

X - 1360 mm

Y - 650 mm

Z - 600 mm


OKK  VM76R

X - 1524 mm

Y - 760 mm

Z - 810 mm


Mori Seki MV-65

X - 1524 mm

Y - 760 mm

Z - 810 mm

[ General Milling / Drilling / Tapping / Profiling / Contouring / Engraving ]




CNC LATHE DIVISION



3 Sizes Of CNC Lathes To Suit Your Needs.  All our lathes are live tool y-axis machines.


MORI SEKI NL 2500

X - 1524 mm

Y - 760 mm

Z - 810 mm

We have 3 of these Mori Seki Lathes


MAZAK Quick Turn Nexus

350-11 MY

X - 440 mm

Y - 100 mm

Z - 2500 mm

We also have manual lathes for jobs that need a more hands on approach.


Acra Turn  CS6266C

X - 3048 mm

can swing up to 610 mm / 24 inches

[ Live Tooling / Turning / Drilling / Thread Cutting / Helical Cutting ]



WIRE EDM

We have 4 state of the art EDM machines.  Our
ROBOCUT C800i-B has the largest cutting capability in North America.  From precision profiles, to complicated corners, our EDM department can find the solution to suit your needs.  We specialize in tall-part wire EDM.  Our EDM machines can hold tolerance to .001 mm.




AgieCharmilles CUT P550

X - 565 mm

Y - 370 mm

Z - 405 mm

Agie-Chamilles CUT P350

X - 365 mm

Y - 240 mm

Z - 305 mm


FANUC Robocut  1iA

X - 540 mm

Y - 390 mm

Z - 305 mm

FANUC Robocut  C800iB

X - 1000 mm

Y - 1000 mm

Z - 600 mm

[ Tall Part EDM / Largest Machine in Canada / Small to Large production runs / Fast turn-around ]


GRINDING - Our newest department!

We have recently acquired a state-of-the art CNC grinding machine.


STUDER  CNC Grinder S33

X - 1000 mm

Y - 400 mm


Okamoto  ACC12-24GX

X - 660 mm

Y - 320 mm

Z - 320 mm


Chevalier    FSG-3A818

X - 410 mm

Y - 200 mm

Z - 300 mm

Kellenberger  1000U

X - 1670 mm

Y - 365 mm


Palmry - Chevalier  CGP-1224

X - 700 mm

Y - 310 mm


Palmry - Chevalier  CGP-1224

X - 700 mm

Y - 310 mm

[ One Off Protyping / Detail Oriented / Quick Turn Around ]


HONING Department



We can hone 4mm to 250 mm id/ and hold tolerance up to .001mm with a surface finish of .02 mm.


SUNNEN   CV-616


SUNEN

[ Precision Internal Diameter / Surface Finish / accuracy up to .001mm ]




FABRICATION Department



Our Fabrication department can take your one off design ideas from the planning stage through to completion.   We regularly design and produce projects for the Defense, Nuclear and Medical Injection Mold industries.

Picture 3.jpg
Borescope Module
Inspection table          2022
Picture 2.jpg

MPI Particle Wash Tank

                  2021


[ You dream it - we make it  ]




CMM MEASURMENT ANALYSIS & QUALITY LAB



Are you not too sure if it is in tolerance, want to see what dimensions you need to hit?  Bring it here for us to fully inspect and verify on 1 of our 2 NIST tracible CMM's.


DEA   IOTA1204

Renishaw retrofit PH20

5 - Axis


Mitutoyo-Bright 710

[ Protype Analysis / Precise Measurment Reports / NIST Tracible Standards ]




PROGRAMMING & CAM/CAD SOLUTIONS



We are in the lead with our CNC Programmers being up to date with the latest MasterCam training and MasterCam programs.

OIP.jfif

[ Protype Design / Custom CNC Programming / CAD Drawings / Up-To-Date EdgeCam Software ]
